Alignments
EN 37Q548.1E LA 6.
2009-Apr-03
Options Digital broadcast DVB Off/On Select DVB On/Off
DVB - T installation Off/On or Country dependent Select DVB T installation On/Off or by country
DVB - T light Off/On Select DVB T light On/Off
DVB - C Off/On Select DVB C On/Off
DVB - C installation Off/On or Country dependent Select DVB C installation On/Off or by country
Over the air download Off/On or Country dependent Select Over the air download On/Off or by country
8 days EPG Off/On Select 8 day EPG On/Off
Digital features USB Off/On Select USB On/Off
Ethernet Off/On Select Ethernet On/Off
Wi-Fi Off/On Select Wi-Fi On/Off
DLNA Off/On Select DLNA On/Off
On-line service Off On-line service is Off
PTP (Picture Transfer Protocol) Off/On Select PTP On/Off
Update assistant Off/On Select Update assistant On/Off
Internet software update Off Internet software update is Off
Display Screen 201 / LCD LGD WUE SBA1 37" Displayed the panel code & type model.
LightGuide Off/On Select LightGuide On/Off
Display fans Not present/Present Select Display fans Present/Not present.
Temperature sensor No sensor N.A
Temperature LUT 0 N.A
E-box & monitor Off/On Select E-box & monitor On/Off
Video reproduction Picture processing None/PNX5120 Select Picture processing None/PNX5120 (Q543.xE
chassis).
MOP local contrast Off/On Select MOP local contrast On/Off
Light sensor Off/On Select Light sensor On/Off
Light sensor type 0/1/2/3 Select Light sensor type form 0 to 3 (for difference
styling).
Pixel Plus type Pixel Plus HD Select type of picture improvement.
Perfect Pixel HD
Pixel Precise HD
Pixel Plus HD (used in Q543.xE)
Pixel Precise HD (used in Q548.1E)
Ambilight None, Select type of Ambilight modules use.
2 sided 2/2
For 8400 series only
2 sided 4/4
3 sided 2/3/2
3 sided 4/3/4
3 sided 4/5/4
4 sided 4/3/4/3
Ambilight technology LED/Future use Ambilight technology LED is in use.
MOP ambilight Off/On Select MOP ambilight On/Off
Audio reproduction Acoustic system Cabinet design used for setting dynamic audio pa-
rameters.
Source selection EXT1/AV1 type SCART CBVS RGB LR Select input source when connected with external
equipment.
CVBS Y/C YPbPr LR
CVBS Y/C YPbPr HV LR
(CVBS) YPbPr LR
EXT2/AV2 type SCART CBVS RGB LR Select input source when connected with external
equipment.
CVBS Y/C LR
(CVBS) YPbPr LR
CVBS Y/C LR
EXT3/AV3 type None Select input source when connected with external
equipment.
CVBS
CVBS LR
YPbPr
YPbPr LR
YPbPr HV LR
VGA Off/On Select VGA On/Off
SIDE I/O Off/On Select SIDE I/O On/Off
HDMI 1 Off/On Select HDMI 1 On/Off
HDMI 2 Off/On Select HDMI 2 On/Off
HDMI 3 Off/On Select HDMI 3 On/Off
HDMI 4 Off/On Select HDMI 4 On/Off
HDMI side Off/On Select HDMI side On/Off
HDMI CEC Off/On Select HDMI CEC On/Off
HDMI CEC RC pass through Off/On Select HDMI CEC RC pass through On/Off
HDMI CEC Pixel Plus link Off/On Select Pixel Plus link On/Off
Main Menu Sub-menu 1 Sub-menu 2 Sub-menu 3 Description
