Philips T Series - IR Connection; IR Pass-Through Connection

32BDL3651T/43BDL3651T
26
4.5. IR connection
[IR IN]
External
IR Receiver
[IR IN]
[IR OUT]
DISPLAY 1 DISPLAY 2
[RS-232 OUT] [RS-232 IN]
DISPLAY 1 DISPLAY 2
NOTE:
1. The remote control sensor of this display will stop working if the [IR IN] is connected.
2. IR loop through connection can support up to 9 displays.
3. IR in daisy chain via RS232 connection can support up to 9 displays.
4.6. IR Pass-through Connection
DVD / VCR / VCD
(DVD / VCR / VCD)
Remote Control
[IR OUT]
[IR IN]
