Phoenix Contact CBMC E4 24DC/1-10A IOL User Manual

CBMC E4 ... IOL
18 / 44
PHOENIX CONTACT 108147_en_00
Nominal current The nominal current for each channel is transmitted in four bits. The valid value range for a
nominal current is limited to entries of 1 … 4 or 1 … 10 depending on the device variants.
Data from BMC IO-Link to the master
The CBMC E4 ... IOL provides the master with its current process data. This contains the
channel status, error status, present load current, and the input voltage of the CBMC E4 ...
IOL. The data is encoded as follows in 8 Byte process input data:
Table 5-2 Bit assignment of data type "CBMC IO-Link to master"
Byte 0 PDin Status
channel
1
Status
channel
2
Status
channel
3
Status
channel
4
Error
channel 1
Error
channel 2
Error
channel 3
Error
channel 4
Bit 63 62 61 60 59 58 57 56
Subindex 1 2 3 4 5 6 7 8
Byte 1 PDin Nominal current channel 1 Nominal current channel 2
Bit 55 54 53 52 51 50 49 48
Subindex 9 10
Byte 2 PDin Nominal current channel 3 Nominal current channel 4
Bit 47 46 45 44 43 42 41 40
Subindex 11 12
Byte 3 PDin Load current channel 1
Bit 39 38 37 36 35 34 33 32
Subindex 13
Byte 4 PDin Load current channel 2
Bit 31 30 29 28 27 26 25 24
Subindex 14
Byte 5 PDin Load current channel 3
Bit 23 22 21 20 19 18 17 16
Subindex 15
Byte 6 PDin Load current channel 4
Bit 15 14 13 12 11 10 9 8
Subindex 16
Byte 7 PDin Input voltage
Bit76543210
Subindex 17
