5.3 Events
The device supports the following events:
Table 5-10 Events
Event code Designation Type Mode Description
36000
dec
8CA0
hex
HW error (power path) OUT1 Error Single event Fuse or MOSFET in power path
OUT1 defective
36001
dec
8CA1
hex
HW error (power path) OUT2 Error Single event Fuse or MOSFET in power path
OUT2 defective
36002
dec
8CA2
hex
HW error (power path) OUT3 Error Single event Fuse or MOSFET in power path
OUT3 defective
36003
dec
8CA3
hex
HW error (power path) OUT4 Error Single event Fuse or MOSFET in power path
OUT4 defective
36016
dec
8CB0
hex
Short circuit switch-off OUT1 Warning Single event OUT1 switched off because of
short circuit
36017
dec
8CB1
hex
Short circuit switch-off OUT2 Warning Single event OUT2 switched off because of
short circuit
36018
dec
8CB2
hex
Short circuit switch-off OUT3 Warning Single event OUT3 switched off because of
short circuit
36019
dec
8CB3
hex
Short circuit switch-off OUT4 Warning Single event OUT4 switched off because of
short circuit
36032
dec
8CC0
hex
Overload shutdown OUT1 Warning Single event OUT1 switched off because of
overload
36033
dec
8CC1
hex
Overload shutdown OUT2 Warning Single event OUT2 switched off because of
overload
36034
dec
8CC2
hex
Overload shutdown OUT3 Warning Single event OUT3 switched off because of
overload
36035
dec
8CC3
hex
Overload shutdown OUT4 Warning Single event OUT4 switched off because of
overload
36048
dec
8CD0
hex
Undervoltage shutdown IN+ Warning Coming/Going Permitted minimum voltage not
reached
36049
dec
8CD1
hex
Surge voltage shutdown IN+ Warning Coming/Going Permitted maximum voltage ex-
ceeded
36056
dec
8CD8
hex
Total current switch off OUT1 Warning Single event Total current switch off trigger:
OUT1 carried maximum current
