5.2.1 IO-Link specific parameters
System commands System command 5
dec
The device supports the possibility of uploading parameters that are changed in the data
memory of the IO-Link master. The parameters that are uploaded when the system com-
mand ("ParamDownloadStore") is called up, are:
– Channel state after voltage reset
– Nominal currents
– Programming locks
Changing a nominal current by button on the device also triggers uploading of the parame-
ters in the data memory of the IO-Link master, insofar as the data memory function in the
master is activated, and the device access lock of the data memory is inactive.
System command 128
dec
The system command allows the controller of the CCBMC E4 ... IOL to be restarted.
System command 130
dec
The system command resets the device to its default settings.
3330
dec
0D02
hex
0 Local program-
ming lock
OUT1-4 4 bytes rw 0; 1 0 - -
1 OUT1 1 byte 0; 1
2 OUT2 1 byte 0; 1
3 OUT3 1 byte 0; 1
4 OUT4 1 byte 0; 1
3331
dec
0D03
hex
0 Nominal current OUT1-4 4 bytes rw 1 – 4 A/
1 - 10 A
4--
1 OUT1 1 byte
2 OUT2 1 byte
3 OUT3 1 byte
4 OUT4 1 byte
3332
dec
0D04
hex
0 Error memory Error history (FIFO) 15 bytes ro - - - -
3333
dec
0D05
hex
0 Output voltages OUT1-4 8 bytes ro 0 - 30 V - 0.1 -
1 OUT 1 2 bytes
2 OUT 2 2 bytes
3 OUT 3 2 bytes
4 OUT 4 2 bytes
Table 5-3 Acyclic data
Index Subindex Name Description Length Access right Value range Default value Gradient Offset
