Process data and status information
108147_en_00 PHOENIX CONTACT 25 / 44
Local programming lock
Bit [0]:
0: Programming mode permitted (standard value)
1: Programming mode blocked for respective channel
If the nominal current should not be programmable by button on all channels, the device ac-
cess lock "Local parameterization lock" can also be used for this.
Nominal current
The nominal current setting can be found under Index 3331. The nominal currents of all
channels can be retrieved under Subindex 0 for read and write access, and the respective
nominal current of a channel is encoded in Bit [0] to Bit [3].
Table 5-6 Bit-assignment of data type "Local programming lock"
Programming lock active/inactive channel 1
Byte 0 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 0 0 0 0 0 0 1/0
Programming lock active/inactive channel 2
Byte 1 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 0 0 0 0 0 0 1/0
Programming lock active/inactive channel 3
Byte 2 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 0 0 0 0 0 0 1/0
Programming lock active/inactive channel 4
Byte 3 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 0 0 0 0 0 0 1/0
Table 5-7 Bit-assignment of data type "Nominal current"
Nominal current channel 1
Byte 0 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 0 0 0 1/0 1/0 1/0 1/0
Nominal current channel 2
Byte 1 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 0 0 0 1/0 1/0 1/0 1/0
Nominal current channel 3
Byte 2 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 0 0 0 1/0 1/0 1/0 1/0
