A Technical appendix
A 1 Technical data
Dimensions (nominal sizes in mm)
Figure A-1 Dimensions
Height 90 mm
Width 36 mm
Depth 98 mm
Ambient conditions
Ambient temperature (operating) -25 °C ... 60 °C
Ambient temperature (storage/transport) -40°C…70°C
Humidity test 96 h, 95% RH, 40°C
Altitude 2000 m
Degree of protection IP20
General
Flammability rating according to UL 94 V-0
Mounting type DIN rail: 35 mm
Color Light gray RAL 7035
Protection class III
Pollution degree 2
Design DIN rail module, one-piece
98
90
36
CBMC
1
2
3
4
1
2
L+
C/Q
1
2
IN+
IN-
OUT+
1
2
3
4
IO-Link
L-
