Process data and status information
108147_en_00 PHOENIX CONTACT 29 / 44
5.4 Device access locks
The device supports three different device access locks. All device access locks are inac-
tive in delivery state and after the "Reset default settings" system command is carried out.
5.5 Data storage (IO-Link data storage)
The device supports the data storage function of IO-Link standard 1.1. The data storage ob-
jects include the nominal currents, the setting of channels after voltage reset, and the pro-
gramming locks for the channels.
36057
dec
8CD9
hex
Total current switch off OUT2 Warning Single event Total current switch off trigger:
OUT2 carried maximum current
36058
dec
8CDA
hex
Total current switch off OUT3 Warning Single event Total current switch off trigger:
OUT3 carried maximum current
36059
dec
8CDB
hex
Total current switch off OUT4 Warning Single event Total current switch off trigger:
OUT4 carried maximum current
Table 5-10 Events
Event code Designation Type Mode Description
Table 5-11 Device access locks
Device access lock Effect
Data storage lock Parameter changes are not uploaded in the data storage of
the IO-Link master.
Local parameterization lock The nominal currents of the channels can no longer be pro-
grammed via the buttons on the device. Display of the nom-
inal current is still possible by pressing the button for a long
time.
The channels can still be switched on and off with the but-
tons.
Local user interface lock All button functions are deactivated.
The channel states are not data memory objects and can be changed either acyclically
per index access or by means of process data outputs (PDout).
