CONTACTRON motor management
8-4
PHOENIX CONTACT 104456_en_01
8.2.2 Software configuration
For this example, the following parameters must be changed in the DTM:
Dialog box Parameter menu Parameter Set value
Configuration Motor output - General Settings Switching output type Direct starter
Monitoring - Monitoring 1
Early warning of dry running, e.g., air
bubble
Activation During right rotation
Monitoring signal Effective power : total
Trigger at Underrange
Behavior Generate message
Acknowledgment Automatic
Monitoring - Monitoring 2
Shutdown in the event of dry running
Activation During right rotation
Monitoring signal Effective power : total
Trigger at Underrange
Behavior Disable drive
Acknowledgment Manual
Monitoring - Monitoring 3
Early warning of blockage
Activation During right rotation
Monitoring signal Effective power : total
Trigger at Overrange
Behavior Generate message
Acknowledgment Automatic
Monitoring - Monitoring 4
Shutdown in the event of blockage
Activation During right rotation
Monitoring signal Effective power : total
Trigger at Overrange
Behavior Disable drive
Acknowledgment Manual
