Phoenix Contact IFS-CONFSTICK User Manual

EM-PB-GATEWAY-IFS PROFIBUS module
104456_en_01 PHOENIX CONTACT 4-41
4.7.6 Example
The following modules are used in this example:
– SIMATIC S7-300
–EM-PB-GATEWAY-IFS
– EMM 3- 24DC/500AC-16-IFS
4.7.6.1 Hardware structure
Figure 4-31 Hardware structure
CPU
IFS address: 1
PROFIBUS address: 2
PROFIBUS address: 4
IFS address: 2
