10 / 22
For PWC - 2950A ONLY
In addition to these parts, the main body of the machine is included.
With some preinstalled parts and internal air lines preinstalled.
c. Positing and Assembly
i. For PWC - 2950 and PWC – 2950A Main Body Assembly
Remove the 4 bolts shown (Fig. 3)
With the help of 2 people, lift and place the
large vertical main column on top of the
changer, align with the bolt holes, place and
tighten the four bolts. (Fig. 4)
Place hexagon mounting bar through hole in
horizontal swivel bar. Then place the large
spring over the hexagon bar. Next with the
help of another person, push spring down
while placing plastic cap on top of hexagon
(Fig. 3)
(Fig. 4)
