Phonic MAX 1000 - Specifications and Dimensions; Technical Specifications

10
MAX 1000
English
Stereo Mode (driving both channels) Continuous Average Output Power Per Channel
8Ω EIA 1kHz 0.1%THD 200W
4Ω EIA 1kHz 0.1%THD 300W
Bridge Mono Mode Continuous Average Output Power
8Ω EIA 1kHz 0.1%THD 600W
Output Circuitry Class AB
Input Sensitivity @ 8Ω 1.23V (+4dBu)
Distortion (SMPTE-IM) <0.01%
Noise (unweighted 20 Hz - 20 kHz below rated
output)
100dB
Damping Factor >300 @ 8Ω
Frequency Response 20 Hz-20KHz, +0/-1dB; -3dB points: 5Hz-50KHz
Input Impedance 20 kΩ balanced, 10 kΩ unbalanced
Cooling Continuous variable-speed fan, front-to-rear air ow
Connectors (each channel) Input: XLR; Output: Speakon and binding posts
Indicators Power: Blue LED; Signal: Green LED; Peak: Red LED
Controls
Front Panel CH1 & CH2 GAIN knobs with 21 detents
Rear Panel
Slide switches: Operation mode: Parallel, Bridge, Stereo;
Current-Break reset button
Protection Circuitry
Short circuit, thermal, subsonic, RF protection,
output DC offset, power on/off muting
Power Comsuption 600W
Power Requirement (depends on region) 100~120VAC, 220~240VAC, 50/60Hz
Dimensions (WxHxD) 482.6 x 88 x 415 mm (19" x 3.46" x 15.9")
Weight 14.6 kg (32.2 lbs)
SPECIFICATIONS
