PI N470 Series User Manual

3 Product Description
N-470 Linear Actuator MP125E Version: 1.2.0 7
In this Chapter
Model Overview ............................................................................................................................. 7
Product View ................................................................................................................................ 10
Product Labeling .......................................................................................................................... 12
Scope of Delivery ......................................................................................................................... 13
Suitable Electronics ...................................................................................................................... 14
Accessories ................................................................................................................................... 14
3.1 Model Overview
The models differ in terms of the following features:
 Travel range
 Type of installation
 Suitability for use in a vacuum
 Position of the cable exit
In the product number, these are coded as follows by the character following the period:
Char
acter following
the period
Meaning Possible values
First character
Travel range
1 = 7.5 mm
2 = 13 mm
4 = 26 mm
Second character
Type of installation
1 = M10
×
1 thread
2 = 9.5 mm clamping shank
Third character Suitability for use in
a vacuum
0 = not suitable
V = up to 10
-6
hPa
U = up to 10
-9
hPa
Fourth character Position of the
cable exit
No entry = standard cable exit
Y = Turned cable exit (i.e., turned by 180°)
3
Product Description
