PI N470 Series User Manual

10 Technical Data
N-470 Linear Actuator MP125E Version: 1.2.0 35
In this Chapter
Specifications ............................................................................................................................... 35
Step Size and Axial Force ............................................................................................................. 39
Lifetime ........................................................................................................................................ 40
Operating Time and Duty Cycle ................................................................................................... 40
Dimensions .................................................................................................................................. 44
Pin Assignment ............................................................................................................................ 46
10.1 Specifications
10.1.1 Data Table
Models that are not suitable for use in a vacuum
Motion and positioning
N-470
Unit
Active axis
X
Travel range
N-470.1xx: 7.5
N-470.2xx: 13
N-470.4xx: 26
mm
Max. step size in step mode
50
nm
Typ. step size
20
nm
Step frequency
2000
Hz
Max. velocity in full-step mode
3.6
mm/min
Typ. velocity in full-step mode
2.4
mm/min
Mechanical properties
N-470
Unit
Mechanical interface
N-470.x1x: M10×1 mounting thread
N-470.x2x: 9.5 mm clamping shank
Stiffness in motion direction
15
N/µm
Feed force (active)
22
N
Holding force (passive)
>100
N
Permissible lateral force
1
N
Drive properties
N-470
Unit
Drive type
Piezo motor
Max. operating voltage
80
V
Max. power consumption
5
W
10
Technical Data
