PI N470 Series User Manual

10 Technical Data
36 Version: 1.2.0 MP125E N-470 Linear Actuator
Miscellaneous
N-470
Unit
Operating temperature range
10 to 40
°C
Material
Screw: Stainless steel
Housing: Aluminum (anodized)
Nut: Bronze
Dimensions
N-470.1xx: 14 × 28 × 48
N-470.2xx: 14 × 28 × 53.5
N-470.4xx: 14 × 28 × 68.5
mm
Mass
80
g
Cable length
2
m
Cable exit
N-470.xxx: Standard
N-470.xxxY: Turned cable exit
Connector
LEMO, 3-pin
Recommended electronics
E-872.401
Ask about customized versions.
Vacuum-compatible models
N-470.x1V
N-470.x1VY
N-470.x1U
N-470.x1UY
N-470.x2V
N-470.x2VY
N-470.x2U
N-470.x2UY
Mechanical interface
M10×1
mounting thread
M10×1
mounting thread
9.5 mm
clamping shank
9.5 mm
clamping shank
Pressure range
10
-6
hPa
10
-9
hPa
10
-6
hPa
10
-9
hPa
Motion and positioning
N-470.11x; N-470.11xx
N-470.12x; N-470.12xx
N-470.21x; N-470.21xx
N-470.22x; N-470.22xx
N-470.41x; N-470.41xx
N-470.42x; N-470.42xx
Unit
Active axis
X
X
X
Travel range
7.5
13
26
mm
Max. step size in step mode
50
50
50
nm
Typ. step size
20
20
20
nm
Max. step frequency
2000
2000
2000
Hz
Max. velocity in full-step
mode
3.6
3.6
3.6
mm/min
Typ. velocity in full-step
mode
2.4
2.4
2.4
mm/min
Mechanical properties
N-470.11x; N-470.11xx
N-470.12x; N-470.12xx
N-470.21x; N-470.21xx
N-470.22x; N-470.22xx
N-470.41x; N-470.41xx
N-470.42x; N-470.42xx
Unit
Stiffness in motion
direction
15
15
15
N/µm
Feed force (active)
22
22
22
N
Holding force (passive)
>100
>100
>100
N
Permissible lateral force
1
1
1
N
Drive properties
N-470.11x; N-470.11xx
N-470.12x; N-470.12xx
N-470.21x; N-470.21xx
N-470.22x; N-470.22xx
N-470.41x; N-470.41xx
N-470.42x; N-470.42xx
Unit
Drive type
Piezo motor
Piezo motor
Piezo motor
Max. operating voltage
80
80
80
V
Max. power consumption
5
5
5
W
