N-470 Linear Actuator MP125E Version: 1.2.0 23
Preparing a vacuum-compatible N-470 for connecting to the electronics
1. Attach the respective connectors for the vacuum feedthrough to the stranded wire
ends of the N-470's cables on the vacuum side and on the air side:
− Make sure that the stranded wires are assigned to each other as shown in the
connection diagram.
− Connect the cable shield according to the figure above. If the cable shield cannot be
connected to a pin, connect the respective cable shield to the housing.
2. Check the lines for contacting and short-circuiting using a suitable measuring device.
