Parameter ID
(hexa-
decimal)
Command
Level
for write
access
Item Type
Concerned
Data
Type
Parameter
Description
Notes
0x07012700 1 PiezoWalk
Channel
FLOAT Time To Close Brake Time to close the brake assigned to a
PiezoWalk channel, in s
To close the brake, for the assigned
output signal channel first the lower limit
for the piezo voltage output is set, and
afterwards the zero voltage value.
0x07012800 1 PiezoWalk
Channel
FLOAT Time To Relax
PiezoWalk Channel
[s]
Duration of the simple relax procedure
for PiezoWalk® drives
If the parameter value is zero (default
setting), the duration depends on the
setting of the PiezoWalk Open-Loop
Velocity parameter (0x07000204).
See p. 12 for further details.
0x07012900 1 PiezoWalk
Channel
FLOAT Anti Creep First
Voltage
Creep reduction procedure for the piezo
actuators of a NEXLINE® drive. If
activated, the creep reduction procedure
is executed immediately after the
iterative relax procedure.
See p. 15 for further details.
0x07012a00 1 PiezoWalk
Channel
FLOAT Anti Creep Second
Voltage
0x07012b00 1 PiezoWalk
Channel
FLOAT Anti Creep Voltage
Slew Rate
0x07012c00 1 PiezoWalk
Channel
INT Anti Creep Sequence
Enable Flag
0x07022000 3 Logical Axis INT Open-Loop Control
Mode
0 = position control
1 = velocity control
2 = velocity control for PiezoWalk® drives,
use OSM and SVA in open-loop
operation
