Parameter ID
(hexa-
decimal)
Command
Level
for write
access
Item Type
Concerned
Data
Type
Parameter
Description
Notes
0x09000201 1 PiezoWalk
Channel
INT PiezoWalk Clamp
Channel 2
Gives the piezo amplifier channel to be
used for the second pair of clamping
components of the PiezoWalk® drive
0x0c000000 1 Amplifier
(Output
Signal
Channel)
FLOAT Soft Voltage Low Limit Gives the lower limit for the piezo voltage
output.
0x0c000001 1 Amplifier
(Output
Signal
Channel)
FLOAT Soft Voltage High Limit
Gives the upper limit for the piezo voltage
output.
0x0e000b06 3 System INT Number Of PiezoWalk
Channels
Maximum possible number of PiezoWalk
channels.
A PiezoWalk channel represents a
PiezoWalk® drive (type can be NEXLINE®,
NEXACT® or PICMAWalk) connected to
the controller.
0x0e000b07 3 System INT Number Of Configured
PiezoWalk Channels
Number of PiezoWalk channels which are
actually configured for use.
The value depends on several
configuration settings for PiezoWalk
channels.
