11_12
FRONT WHEEL REMOVAL
Remove the front wheel by following this procedure:
Turn off the vehicle so that it is not dangerous for the traffic in order to remove the
wheel safely. Put on the hand brake.
11_13
Temporary remove the wheel cup. Keep the wheel on the ground and loosen the nuts
connecting the wheel to the hub.
11_14
Place the jack under the central strut by matching the strut's ribs and the jack's
grooves.
65
