Heating and demisting (08_03)
Cabin defrosting/heating controls (gasoline):
Control bar «B» in position 2 (travel end forward).
Shuttering outlets «D» in position 1 (OPEN).
08_04
Heating and demisting (08_03, 08_04)
Cabin defrosting/heating controls (diesel):
Control bar «B» in position 2.
08_05
Demisting (08_05)
Cabin defrosting controls (gasoline):
Control bar «B» in position 2 (travel end forward).
Shuttering outlets «D» in position 2 (CLOSED).
The hot air flow is thus sent to the windscreen only, through the two outlets shown in
the figure.
