FRONT SUSPENSION UNIT
Name Torque in Nm
Shock absorber upper anchoring nut 30-40
Shock absorber lower anchoring nut 100-120
Steering upper bearing lock gear 50 to 70
Wheel rim to drum locking 60-70
Wheel locking centre nut 100-120
Shoes self-centring plate lock nuts 20 - 25
REAR SUSPENSION UNIT
Name Torque in Nm
Wheel to drum lock nut 60-70
Drum centre lock nut 200 to 240
Shock absorber lower lock nut 100 to 140 Nm
Shock absorber upper lock nut 30-40
Swinging arm lock nut 40-50 Nm
Flexible coupling lock nut 40 - 50
Hub to axle shaft lock nut 50-70
Hub to wheel axle lock nut 140-180
Hub to swinging arm lock nut 40 - 50
Shoes self-centring plate lock nut 18 to 20 Nm
FRAME ASSEMBLY
Name Torque in Nm
Handle bar to steering tube lock bolts 42 to 52 (a)
Steering control lever to steering tube lock bolts 30 to 35
Steering housing lock nuts 20 to 25 (b)
Steering wheel lock nut 30 to 35 (b)
Rack pressure roller lid lock nuts 8 to 12 (b)
Pressure roller adjustment screw lock nut 40 to 60 (b)
Lever holder locking screw 7 to 8.5
Brake oil pump piston end stroke screw 6 to 10 Nm
Pedal assembly bolt lock nut 15 to 25
Stop switch 1.5 to 3
Cab doors lock bolt 23 to 30
Windshield wiper motor lock 8 to 9
Brake pump body lock bolts 12 to 20 (a)
Brake pump body lock bolts 8 to 12
Floor to cab panel lock bolts 20 - 25
Floor to centre cross member lock nuts 20 - 25
(a) Specific for versions with handlebar
(a) Specific for versions with steering wheel
Vehicle overhaul data
Assembly clearances
SHOULDER RINGS
Specification
Desc./Quantity
Shoulder ring (Nominal sizes) B= 1 +0 -0.06 (mm)
APE TM Benzina Characteristics
CH - 19
