Scheduled maintenance chart
MAINTENANCE OPERATIONS - APE TM
In the event of prolonged vehicle inactivity, adhere to the following standards:
1) Clean the vehicle
2) Remove the fuel from the vehicle
3) Remove the air filter, and with the engine running at low speed and put 30 cc. of specific oil through the diffuser of the carburettor.
4) Apply antirust grease to the unpainted metal parts
5) Lift the wheels off the ground.
A) Operation to be performed with the engine warm. Amount of new oil: approximately 885 gr., keeping in mind that in the controls
of the oil level it must always be between the "min." and "max" positions marked on the rod of the cover.
B) Operation to be performed with bent iron wire or also with compressed air fed into the nozzle fastening to the cylinder, after
heating of the external exhaust pipe.
C) Use the specific oil to restore the oil level in the tank and for replacement.
*) Mainly use of the vehicle on dusty roads; clean the filter housing and replace the filter cartridge more frequently.
Unit After the
first 1000
km
Every
4000 km
Every
8000 km *)
= every
16000 km
In the
event of a
review
Notes
ENGINE
Carburettor locking • See the table of locking torque
Piston - big end - cylinder lights des-
caling
• See the table of locking torque
Cleaning and descaling of the still
usable engine parts
• See the table of locking torque
TRANSMISSION - DIFFERENTIAL
Oil replacement • (▲ - A) • (▲ - A) • (▲) Specific (▲) oil
Check and restore oil level • (▲) IP DUE T (▲) oil
air filter
Replace *)•
SPARK PLUG
Electrode gap and descaling check • • Marelli CW 7N; Bosch W 4AC-Lodge
3HN; Champion L82-AC430Z; NGK
B7HS
Replacement • Marelli CW 7N; Bosch W 4AC-Lodge
3HN; Champion L82-AC430Z; NGK
B7HS
SILENCER
Cleaning of the exhaust pipe •(B)
BEARINGS
Grease •(◘) •(◘) (◘) IP Athesia Grease 3 or FIAT Jota
3 Grease
ARTICULATIONS AND CONTROL
LEVERS (ENGINE SIDE)
Grease •(+) •(+) (+) IP Autogrease LZ or FIAT Zeta 2
Grease
HYDRAULIC BRAKE
Check and restore oil level •(x-C) •(+) (+) IP Autofluid FR Oil or FIAT Blue
label DOT 3 Liquid
FLEXIBLE TRANSMISSIONS
Adjust •
Lubricate •(■) •(■)
MAIN NUTS AND BOLTS OF THE
VEHICLE
Locking check • • See the table of locking torque
MAINTENANCE OPERATIONS - APE TM KAT
* = check.
• = replacement.
(*)= every two years.
(**)= every 12000 km / 36 months.
Maintenance APE TM Benzina
MA - 32
