PIAGGIO Ape - Page 33

x 1000 Km - (Months) 1
(4)
5
(12
)
10
(24
)
15
(36
)
20 25 30 35 40 45 50 55 60 65 70 75 80 85 90
Battery - check/top-up * * * * * * * * * * * * * * * * * *
Safety blocks - Check * * * * * * * * * *
Carburetion - Inspection/Ad-
justment
* * * * * * * * * *
Ignition spark plug - Replace-
ment
• • • • • • • • • • • • • • • • • •
Door hinges - Lubrication * * * * * * * * *
Dynamotor belt - Inspection/
Adjustment
* * * * * * * * * * * * * * * * * * *
Transmissions (gas, clutch,
drive) - Inspection/Adjust-
ment
* * * * * * * * * *
Tyre wear and inflation pres-
sure - Inspection
* * * * * * * * * * * * * * * * * * *
Air filter - Replacement • • • • • • • • •
Parking brake - Adjustment * * * * * * * * * * * * * * * * * * *
Electrical system - Inspection * * * * * * * * * *
Cylinder and fan system - In-
spection
* * * *
Light transmission on the en-
gine - Lubrication
• • • • • • • • • • • • • • • • • •
Brake fluid level - Inspection * * * * * * * * * * * * * * * * * * *
Brake fluid - Replacement (*) (*) (*) (*) (*) (*) (*) (*) (*) (*) (*) (*) (*) (*) (*) (*) (*) (*) (*)
Engine oil and differential -
Replacement
• • • • • • • • • •
Headlight - Inspection/Ad-
justment
* * * * * * * * * *
Vehicle and brake test - In-
spection
* * * * * * * * * * * * * * * * * * *
Suspension - Inspection * * * * * * * * *
Piston cylinder head exhaust
port - Cleaning
• • • • • • • • •
Flexible transmissions - Lu-
brication
• • • • • • • • • • • • • • • • • •
Exhaust pipe - Cleaning • • • • • • • • •
Pressure flexible brake pipes
- Replacement
• • •
Cleaning air filter and SAS
box (sponge) - Inspection/
Replacement
* • * • * • * • * • * • * • * • * •
SAS reed support - replace-
ment
(**) (**) (**) (**) (**) (**) (**) (**) (**) (**) (**) (**) (**) (**) (**) (**) (**) (**) (**)
Labour time 90' 65' 20
0'
65' 22
5'
65' 24
0'
65' 22
5'
65' 11
0'
65' 26
0'
65' 20
0'
65' 22
5'
65' 24
0'
MAINTENANCE OPERATIONS - APE TM P703 FL2
* = check.
• = replacement.
(*)= every two years.
x 1000 Km - (Months)
1
(4)
5
(12
)
10
(24
)
15
(36
)
20 25 30 35 40 45 50 55 60 65 70 75 80 85 90
Battery - check/top-up * * * * * * * * * * * * * * * * * *
Safety blocks - Check * * * * * * * * * *
Carburetion - Inspection/Ad-
justment
* * * * * * * * * *
Ignition spark plug - Replace-
ment
• • • • • • • • • • • • • • • • • •
Door hinges - Lubrication * * * * * * * * *
Dynamotor belt - Inspection/
Adjustment
* * * * * * * * * * * * * * * * * * *
Transmissions (gas, clutch,
drive) - Inspection/Adjust-
ment
* * * * * * * * * *
APE TM Benzina Maintenance
MA - 33
