17. Windscreen wiper switch
18. Switch for external lighting
19. Protection 8A fuse valves to electrical system
20. 12V - 24Ah battery
21. Switch for external lighting with horn button
22. Turn indicator switch
23. Ceiling lighting bulb inside the cab 12V - 4W
24. Electronic control unit
25. Spark plug
26. Flywheel fan
27. Dynamotor
28. Heated switch
29. Oil tank level indicator
30. Rear stop lights switch
31. Fuel tank level indicator
32. Rear turn indicators, 12V - 21W bulbs
33. Rear position lights and stop lamps 12V - 5/21W.
WARNING
THE MARKS --- INDICATE THE ELECTRICAL INSTALLATION VARIANTS FOR THE VAN BODY-
WORK.
KEY:
A. 8A Protective fuse valve.
B. Lamp for lighting inside the van.
C. Push-button light switch, controlled by the back door.
N.B.
THE ELECTRICAL SYSTEM DIAGRAM FOR THE TIPPER VERSION DIFFERS DUE TO THE AD-
DITION OF A SENSOR (OPERATED BY THE DECK POSITION AT TIME OF DETACHMENT)
LINKED BY A GREY CABLE TO A RED WARNING LIGHT (LAMP 12V - 1.2 W) MOUNTED ON THE
CENTRE OF THE DASHBOARD.
Electrical system diagram (version with handlebar) - APE TM P703 FL2
APE TM Benzina Electrical system
ES - 49
