PIAGGIO Beverly 300ie User Manual

01_10
Light switch (01_10)
When the light switch «A» is in position «0» the low-beam light is ON; when it is in
position «1» the high-beam light is ON. If the light switch «A» is pressed when set to
«2», the high-beam light flashing is activated. The switch goes back to «0» automat-
ically.
CAUTION
DO NOT CARRY ANY GARMENTS ON THE FRONT HEADLIGHT ASSEMBLY.
THIS MAY CAUSE BULBS TO OVERHEAT AND THEREFORE ABNORMAL
WEAR.
01_11
Start-up button (01_11)
Starter button «A». To start the vehicle, refer to the "starter motor" section.
15
1 Vehicle

PIAGGIO Beverly 300ie Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	278 cc
Cooling System	Liquid-cooled
Fuel System	Electronic fuel injection
Front Suspension	Hydraulic telescopic fork
Rear Suspension	Dual hydraulic shock absorbers
Rear Brake	240 mm disc
ABS	Yes
Seat Height	790 mm
Fuel Capacity	12 liters
Width	780 mm
Max Torque	22.5 Nm @ 5, 750 rpm
Transmission	CVT
Top Speed	125 km/h
