PIAGGIO Beverly 300ie User Manual

03_43
Front direction indicators (03_43, 03_44, 03_45)
To replace the indicator bulbs proceed as follows:
- Open the front case
- Remove the rubber protection
- Remove the lamp holder, rotating it towards the inside of the vehicle
- Lightly press the lamp and turn it anticlockwise and remove it.
03_44
03_45
WARNING
THE DAYLIGHT RUNNING LIGHTS PRESENT IN THE SAME GROUP ARE «LED»
TYPES. IN CASE OF MALFUNCTIONING, AS THE REMOVAL IS PARTICULARLY
DIFFICULT, WE ADVISE ADDRESSING AN Authorised PIAGGIO Service Centre
FOR THE REPLACEMENT.
63
3 Maintenance

PIAGGIO Beverly 300ie Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	278 cc
Cooling System	Liquid-cooled
Fuel System	Electronic fuel injection
Front Suspension	Hydraulic telescopic fork
Rear Suspension	Dual hydraulic shock absorbers
Rear Brake	240 mm disc
ABS	Yes
Seat Height	790 mm
Fuel Capacity	12 liters
Width	780 mm
Max Torque	22.5 Nm @ 5, 750 rpm
Transmission	CVT
Top Speed	125 km/h
