PIAGGIO Beverly 300ie User Manual

03_11
03_12
Spark plug dismantlement (03_11, 03_12)
Proceed as follows:
- Remove the case that grants access to the spark plug located on the right side fairing
by unscrewing the indicated screw.
- Disconnect cap «A» from the spark plug HV cable by turning it clockwise until re-
leasing it from the retainer.
- Unscrew the spark plug using the wrench supplied.
- When refitting, place the spark plug into the hole at the corresponding angle and
finger tighten it as far as it will go. Use the wrench only to tighten it.
- Place cap «A» fully over the spark plug, making sure it is in the retainer again.
WARNING
SPARK PLUG MUST BE REMOVED WHEN THE ENGINE IS COLD. REPLACE
THE SPARK PLUG AS INDICATED IN THE SCHEDULED MAINTENANCE TABLE.
THE USE OF ELECTRONIC CENTRAL UNITS AND OF NON-COMPLIANT ELEC-
TRONIC IGNITIONS OR SPARK PLUGS OTHER THAN THOSE PRESCRIBED
MAY SERIOUSLY DAMAGE THE ENGINE.
N.B.
USE OF SPARK PLUGS OTHER THAN THE INDICATED TYPE OR UNSHIELDED
SPARK PLUG CAPS CAN LEAD TO FAULTS IN THE VEHICLE 'S ELECTRICAL
SYSTEM.
47
3 Maintenance

PIAGGIO Beverly 300ie Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	278 cc
Cooling System	Liquid-cooled
Fuel System	Electronic fuel injection
Front Suspension	Hydraulic telescopic fork
Rear Suspension	Dual hydraulic shock absorbers
Rear Brake	240 mm disc
ABS	Yes
Seat Height	790 mm
Fuel Capacity	12 liters
Width	780 mm
Max Torque	22.5 Nm @ 5, 750 rpm
Transmission	CVT
Top Speed	125 km/h
