PIAGGIO MP3 LT 400 i.e. - Page 72

FUSE TABLE
Fuse No. 1 Capacity: 7.5 A
Protected circuits:Injection ECU
battery power
Fuse No. 2 Capacity: 15 A
Protected circuits:Battery-
powered injection loads, electrical
fan
Fuse No. 3 Capacity: 15 A
Protected circuits:Saddle
opening receiver battery power
supply, glove box lighting,
headlight, turn indicator command
device, pre-installation for anti-
theft device.
Live fuse No.12, saddle opening
and boot.
Fuse No. 4 Capacity: 20A
Protected circuits:battery-
powered ECU for parking control
Fuse No. 5 Capacity: 20A
Protected circuits:battery-
powered fuse No. 7, live fuses No.
8 - 9 - 10 - 11
Fuse No. 6 Capacity: 15 A
72
3 Maintenance
