Protected circuits:L.V. socket.
Fuse No. 7 Capacity: 7.5 A
Protected circuits:Battery-
powered instrument panel
Fuse No. 8 Capacity: 10A
Protected circuits:Live stop,
start-up and start-up enabling
lights.
Fuse No. 9 Capacity: 7.5 A
Protected circuits:live passing
and horn
Fuse No. 10 Capacity: 7.5A
Protected circuits:Live injection
ECU, immobilizer aerial, electric
fan remote control, injection load
remote control
Fuse No. 11 Capacity: 7.5A
Protected circuits:Live parking
control ECU, pre-installation for
anti-theft device, instrument panel,
headlight remote control, horn
remote control
Fuse No. 12 Capacity: 7.5A
Protected circuits:Live turn
indicator control, saddle opening
switch, tail lights, panel lighting
73
3 Maintenance
