Number plate light
Remove the snap-on bulb holder by working from below the rear mudguard.
03_38
Helmet compartment lighting bulb (03_38)
Open the helmet compartment, take out the pressure mounted transparent cover
"D" and replace the bulb.
03_39
Brake light (03_39)
In order to slide off the whole assembly, open the helmet compartment, remove the
saddle lock cap as described above and remove the 3 screws «E» (one top and the
other 2 side screws). Burnt out bulbs can be replaced by turning the bulb holder 30°
anticlockwise.
66
