01_01
01_02
01_03
Dashboard (01_01, 01_02, 01_03)
A = Key switch
B = Start-up button
C = Accelerator control
D = Front brake control
E = Saddle electric opening button
F = Digital instrument panel
G = Direction indicator switch
H = Light switch
I = Combined braking control (front and rear)
L = Horn button
M = Engine lock RUN-OFF switch
N = Emergency flashing light start button (4 direction indicators)
O = Indicator unir
P = Button fitting
R = Analogue instrument unit
8
