DON'T REMOVE THE MICROPHONE CAPSULE PROTECTION.
Insert both headsets into the connectors; the pilot's is the front one, the passenger's is the rear one.
Move the ignition key to ON and the intercom will start automatically, at the low level (LOW); the intercom
can be started in manual mode too.
Adjust the volume using buttons (X) (R).
The voice activation level can be switched to two levels (high; low).
In automatic mode, the intercom starts automatically when the pilot or the passenger talk, and it remains
active for 20 seconds at the end of the talk (be careful to the level set).
To switch it to the high level (HIGH), press button (M) and then button (S) when the radio function is
displayed.
A mobile phone can be connected to the device using the special cable (D) (see Piaggio accessories);
when a call is received, a tone is heard by both the passenger and the pilot; after the tone, the call is
switched to the pilot, with the possibility of switching it to the passenger by button (Y). The call can be
temporarily interrupted by button (W) to switch to the intercom, and then resumed pressing the same
button.
In any case, when the call is received, the control unit emits a short sound on both loudspeakers,
optionally with the phone's tone, if the phone model has one.
When the vehicle is stopped, if a call is in progress the control unit remains on until the conversation is
ended.
The mobile phone should be set to the automatic answer function to prevent having to press a key to
start the conversation.
For the models not provided with this function: you can select the answer by any key option.
The conversation volume can only be set by the mobile phone.
The volume should be set to maximum.
It is possible to connect a scatterer (2.5 W max) by the external scatterer socket (see figure 1). Besides
the radio, intercom and handsfree kit functions, it is possible to connect the control unit to a portable
CD reader or a walkman by a cable with stereo jack termination 3.5 mm. Adjust the external source
volume so that it can be heard corrctly without having to adjust the intercom volume.
During a conversation in intercom mode, the audio from the radio or from the external source remains
in background at a lower volume.
N.B.
ALWAYS REFER TO THE USE MANUAL OF YOUR MOBILE PHONE TO SET UP THE FUNCTIONS
DESCRIBED ABOVE.
N.B.
THE USERS OF MOTOROLA 8700, STARTAC 130™ CD920 CD930 AND BOSCH M-COM 506
MUST CONNECT THEIR MOBILE TO THE CONTROL UNIT WITH PHONE OFF: THE PHONE WILL
SWITCH ON AUTOMATICALLY.
Electrical system X9 Evolution 500
ELE SYS - 70
