This section è is devoted to the operations that can be carried out on the vehicle's bodywork.
Seat
•
Raise the saddle
•
Undo the three screws fixing the plate
to the central cover and remove the
saddle.
Side fairings
•
Remove the side panel
•
Undo the three clamping screws of the
bumper band and remove it.
See also
Side fairings
Driving mirrors
•
Remove the joint rubber of the mirror
housing from the bottom;
•
Unscrew the two screws, then remove
the covering from the support arm;
•
Remove the 2 lower retainers fixings
the mirror to the frame.
Chassis XEVO 125 Euro 3
CHAS - 2
