PIAGGIO XEVO 125 Euro 3 User Manual

- Undo the 4 screws (2 per side) on the sides of
the helmet compartment.
- Raise the helmet compartment as much as pos-
sible;
- Disconnect the electrical connection of the two
light buttons;
- Remove the glove box flap hook;
- Remove the saddle hook;
- Disconnect the spark plug HV wire.
- Pull the right and left fuse box out downwards
freeing the tooth with a screwdriver from above;
- Slide off the battery positive and negative leads
and the diagnostics socket from the side slots.
See also
Side fairings
Frame central cover
Fuel tank
- Remove the central chassis cover.
- Remove the footrest.
- Remove the three tank retainers.
- Disconnect the electric wiring and the fuel pipes.
Chassis XEVO 125 Euro 3
CHAS - 14
