Rear handlebar cover
•
- Remove the front handlebar cover
•
Undo the 3 screws fixing the rear han-
dlebar cover and remove the cover
once the connectors of the controls
have been disconnected.
See also
Front handlebar cover
Instrument panel
•
Remove the instrument panel support
and tip it.
•
Undo the six fixing screws «A» to re-
move the instrument panel.
See also
Analogue instrument panel support
Front handlebar cover
•
Undo the three screws«A» fixing the
handlebar upper cover and slide it off
upwards.
XEVO 125 Euro 3 Chassis
CHAS - 3
