Pilatus PC12 - Standard Torque Values; Documents Required; Consumable Products; Table 1 Standard Torque Values

Component Maintenance Manual
EFFECTIVITY: ALL
21-00-22
Introduction
Page 10
JULY 21, 2011
SUBTASK 21-00-22-99F-003
1.3 Standard Torque Values:
TYPE FASTENER
DESCRIPTION/LOCATION TORQUE
.25-28 SET SCREW ALL LOCATIONS 40-50 IN LBS
6-32 SCREW AN500-6-6, MS35265-30, ALL
LOCATIONS
7-9 IN-LBS
8-32 SCREW AN500-A8-6, MS35265-45, ALL
LOCATIONS
12-15 IN-LBS
10-32 SCREW ALL LOCATIONS 60-75 IN-LBS
¼-28-UNF ALL LOCATIONS 135-185 IN-LBS
5/16-24UNF ALL LOCATIONS 270-360 IN-LBS
3/8-24UNF AN6-10A, AN6-14A, ALL LOCATIONS 270-360 IN-LBS
5/8-18 PLUMBING
CONNECTIONS
RECEIVER DRYER
SUCTION/DISCHARGE PORT
132-156 IN-LBS
7/8-14 PLUMBING
CONNECTIONS
COMPRESSOR SUCTION PORT 252-324 IN-LBS
¾-16 PLUMBING
CONNECTIONS
COMPRESSOR DISCHARGE PORT 180-240 IN LBS
7/16-20 PLUMBING
CONNECTIONS
EXPANSION VALVE INLET PORT 100-140 IN LBS
¾-16 PLUMBING
CONNECTIONS
EXPANSION VALVE OUTLET PORT 270-350 IN LBS
Table 1 Standard Torque Values
SUBTASK 21-00-22-99F-004
1.4 Documents Required:

Illustrated Parts Listings (IPL) (included with this manual)
 Pilatus PC12 Aircraft Maintenance Manual
SUBTASK 21-00-22-99F-005
1.5 Consumable Products:
PART NUM
BER DESCRIPTION REMARKS
11602 SEALANT RTV BLACK
7471 THREAD SEALANT PRIMER LOCTITE
569 THREAD SEALANT LOCTITE
BVM100N REFRIGERANT OIL R12
Table 2 Consumable Products
