Pilatus PC12 - Figure 10002 Evaporator Module Assembly (1250200-42;-43) Details

Component Maintenance Manual
EFFECTIVITY: ALL
21-00-22
Figure 10002
Page 10006
JULY 21, 2011
FIG. ITEM
PART NUMBER NOMENCLATURE UNITS ASSY.
10002-10A 1250218 EXPANSION VALVE (-42) 1
1250218-1 EXPANSION VALVE (-43) 1
20B 1250540-11 AIR FILTER 1
-21 190940 VELCRO (HOOK) (2.6 FT.) 1
-22 190911 VELCRO (LOOP) (2.6 FT.) 1
30A BLOWER MOTOR N/P
40A SHROUD N/P
50B ESCUTCHEON N/P
Figure 10002 Evaporator Module Assembly (1250200-42/-43) Details
- ITEMS NOT ILLUSTRATED
N/P ITEMS NOT PROCURABLE
