Pilatus PC12 - Figure 10001 Compressor Condenser Module Assembly (1250900-4) Details Cont

Component Maintenance Manual
EFFECTIVITY: ALL
21-00-22
Figure 10001
Page 10004
JULY 21, 2011
100A 1250509 SHROUD 1
-101 10-32X3/8IHW SCREW 4
-102 NAS1149F0332P FLAT WASHER (AN960-10L) 4`
-103 409-1032Z NUT 4
110A 1250502-3 CONDENSER SUPPORT BRACKET 1
-111 AN500-A8-6 SCREW 4
-112 NAS1149FN832P FLAT WASHER (AN960-8) 4
-113 MS35265-30 SCREW 2
-114 NAS1149FN632P FLAT WASHER (AN960-6) 2
120C 1250703-1 HOUR METER 1
-121 AN500-6-6 SCREW 2
-122 NAS1149FN632P FLAT WASHER (AN960-6) 2
-123 409-1032Z NUT 2
130 CONDENSER ASSEMBLY N/P
Figure 10001 Compressor Condenser Module Assembly (1250900-4) Details Cont.
- ITEMS NOT ILLUSTRATED
N/P ITEMS NOT PROCURABLE
