Pilatus PC12 - Figure 10001 Compressor Condenser Module Assembly (1250900-4) Details

Component Maintenance Manual
EFFECTIVITY: ALL
21-00-22
Figure 10001
Page 10003
JULY 21, 2011
FIG. ITEM PART NUMBER NOMENCLATURE UNITS ASSY.
10001-10C 1250104 DC MOTOR 1
-11C 5/16-24X3/4H BOLT 8
-12C MS35333-41 WASHER 8
-13C 1251171
MOTOR BRUSH(SET CONTAINS 4 BRUSH
PAIRS)
1
10B 1250128 POWER RELAY 1
-11B ¼-28X1/2H BOLT 1
-12B ¼-28X1H BOLT 1
-13B 21FK-428 NUT 2
-14B MS35333-40 FLAT WASHER 1
-15B AN345-416 NUT 1
-16B NAS1149F0463P FLAT WASHER (AN960-416) 4
-17B MS25171-3 LARGE BOOT 3
-18B MS25171-1 SMALL BOOT 2
20C 1250146-5 DRIVE PULLEY 1
-30 1250170 FAN BLADE 1
-31 ¼-28X5/16B SET SCREW 2
-32 NAS1149F0463P FLAT WASHER (AN960-416) 3
-33 21FK-624 NUT 1
40A 1250120 COMPRESSOR ASSEMBLY 1
-41 AN6-10A BOLT 2
-42 21FK-624 NUT 4
-43 NAS1149F0463P FLAT WASHER (AN960-416) 7
-44 TM-6 ROD END 1
-45 21FK-624 NUT 1
-46 NAS1149F0463P FLAT WASHER (AN960-416) 1
-47 AN6-14A BOLT 1
-48 8-8-070221 SWIVEL FITTING 1
-49 10-10-070221 SWIVEL FITTING 1
50C 1250140-9 RECEIVER DRYER 1
60A 1250232-4 BINARY PRESSURE SWITCH 1
70C QS100M36H CLAMP 1
80C 1250199-5 BELT COVER 1
-81 6-32X1/2IHS SCREW 4
90C 240L100 DRIVE BELT 1
Figure 10001 Compressor Condenser Module Assembly (1250900-4) Details
- ITEMS NOT ILLUSTRATED
N/P ITEMS NOT PROCURABLE
