Pilatus PC12 - Page 8

Component Maintenance Manual
EFFECTIVITY: ALL
21-00-22
List of Tables
Page 7
JULY 21, 2011
LIST OF ILLUSTRATIONS
Figure 2 R12 Refrigerant Flow Schematic.................................................................................................2001
Figure 3 Brush Removal Details.................................................................................................................3005
Figure 4 Commutator In Excellent Condition...........................................................................................5002
Figure 5 Commutator In Serviceable Condition ......................................................................................5003
Figure 6 Commutator In Unserviceable Condition ..................................................................................5004
Figure 7 Belt Tensioning Reference...........................................................................................................7006
Figure 10001 Compressor Condenser Module Assembly 1250900-4...................................................10002
Figure 10001 Compressor Condenser Module Assembly (1250900-4) Details ...................................10003
Figure 10001 Compressor Condenser Module Assembly (1250900-4) Details Cont. .........................10004
Figure 10002 Evaporator Module Assembly 1250200-42 (L) /-43 (C,R) ................................................10005
Figure 10002 Evaporator Module Assembly (1250200-42/-43) Details .................................................10006
LIST OF TABLES
Table 1 Standard Torque Values ....................................................................................................................10
Table 2 Consumable Products .......................................................................................................................10
Table 3 Trouble Shooting List ....................................................................................................................1005
Table 3 Trouble Shooting List ....................................................................................................................1006
Table 3 Trouble Shooting List ....................................................................................................................1007
Table 3.5 Compressor Condenser Module Inspection Schedule............................................................5001
Table 3.6 Forward and Aft Evaporator Module Inspection Schedule.....................................................5005
Table 4 Typical Operating Values.............................................................................................................11001
Table 5 Refrigerant Charge.......................................................................................................................14003
