PNOZ 16
Operating Manual PNOZ 16
1003517-EN-09
| 12
Preparing for operation
Supply voltage AC DC
FE
B1
B2
L+
L-
Input circuit Single-channel Dual-channel
E-STOP
without detection of shorts across
contacts
S1
S22
S21
S12
S32
S11
S31
E-STOP
with detection of shorts across
contacts
S1
S22
S31
S32
S21
S12
S11
Safety gate
without detection of shorts across
contacts
S1
S22
S21
S12
S32
S11
S31
Safety gate
with detection of shorts across
contacts
Short circuit-forming pressure
sensitive mat/edge
S12
S11
S22
S32
S21
S31
