PNOZ 16
Operating Manual PNOZ 16
1003517-EN-09
| 24
Technical Details Order No. 774066-774067
General 774066 774067
Certifications
CCC, CE, EAC (Eurasian), TÜV,
cULus Listed
CCC, CE, EAC (Eurasian), TÜV,
cULus Listed
Electrical data 774066 774067
Supply voltage
Voltage 230 V 240 V
Kind AC AC
Voltage tolerance -15 %/+10 % -15 %/+10 %
Output of external power supply
(AC) 3,5 VA 3,5 VA
Frequency range AC 50 - 60 Hz 50 - 60 Hz
Supply voltage
Voltage 24 V 24 V
Kind DC DC
Voltage tolerance -15 %/+10 % -15 %/+10 %
Output of external power supply
(DC) 2 W 2 W
Residual ripple DC 20 % 20 %
Duty cycle 100 % 100 %
Inputs 774066 774067
Number 2 2
Voltage at
Input circuit DC 24 V 24 V
Start circuit DC 24 V 24 V
Feedback loop DC 24 V 24 V
Current at
Input circuit DC 25 mA 25 mA
Start circuit DC 25 mA 25 mA
Feedback loop DC 25 mA 25 mA
Min. input resistance at power-on 49 Ohm 49 Ohm
Max. overall cable resistance Rl-
max
Single-channel at UB DC 40 Ohm 40 Ohm
Single-channel at UB AC 40 Ohm 40 Ohm
Dual-channel with detection of
shorts across contacts at UB DC 80 Ohm 80 Ohm
Dual-channel with detection of
shorts across contacts at UB AC 80 Ohm 80 Ohm
Max. safety mat resistance 80 Ohm 80 Ohm
Relay outputs 774066 774067
Number of output contacts
Safety contacts (N/O), instant-
aneous 2 2
Max. short circuit current IK 1 kA 1 kA
