Pilz PNOZ 16 User Manual

PNOZ 16
Operating Manual PNOZ 16
1003517-EN-09
| 16
Inputs 774060 774061 774062
Current at
Input circuit DC 25 mA 25 mA 25 mA
Start circuit DC 25 mA 25 mA 25 mA
Feedback loop DC 25 mA 25 mA 25 mA
Min. input resistance at
power-on 49 Ohm 49 Ohm 49 Ohm
Max. overall cable resist-
ance Rlmax
Single-channel at UB
DC 40 Ohm 40 Ohm 40 Ohm
Single-channel at UB
AC 40 Ohm 40 Ohm 40 Ohm
Dual-channel with de-
tection of shorts across
contacts at UB DC 80 Ohm 80 Ohm 80 Ohm
Dual-channel with de-
tection of shorts across
contacts at UB AC 80 Ohm 80 Ohm 80 Ohm
Max. safety mat resist-
ance 80 Ohm 80 Ohm 80 Ohm
Relay outputs 774060 774061 774062
Number of output con-
tacts
Safety contacts (N/O),
instantaneous 2 2 2
Max. short circuit current
IK 1 kA 1 kA 1 kA
Utilisation category
In accordance with the
standard EN 60947-4-1 EN 60947-4-1 EN 60947-4-1
Utilisation category of
safety contacts
AC1 at 240 V 240 V 240 V
Min. current 0,01 A 0,01 A 0,01 A
Max. current 8 A 8 A 8 A
Max. power 2000 VA 2000 VA 2000 VA
DC1 at 24 V 24 V 24 V
Min. current 0,01 A 0,01 A 0,01 A
Max. current 8 A 8 A 8 A
Max. power 200 W 200 W 200 W
Utilisation category
In accordance with the
standard EN 60947-5-1 EN 60947-5-1 EN 60947-5-1

Pilz PNOZ 16 Specifications

General

Brand	Pilz
Model	PNOZ 16
Category	Relays
Language	English
