Pilz PNOZ 16 User Manual

PNOZ 16
Operating Manual PNOZ 16
1003517-EN-09
| 18
Times 774060 774061 774062
Switch-on delay
With automatic start
typ. 230 ms 230 ms 230 ms
With automatic start
max. 350 ms 350 ms 350 ms
With automatic start
after power on typ. 310 ms 310 ms 310 ms
With automatic start
after power on max. 450 ms 450 ms 450 ms
With manual start typ. 230 ms 230 ms 230 ms
With manual start max. 350 ms 350 ms 350 ms
Delay-on de-energisation
With E-STOP typ. 18 ms 18 ms 18 ms
With E-STOP max. 30 ms 30 ms 30 ms
With power failure typ. 50 ms 50 ms 50 ms
With power failure max. 100 ms 100 ms 100 ms
Recovery time at max.
switching frequency 1/s
After E-STOP 50 ms 50 ms 50 ms
After power failure 100 ms 100 ms 100 ms
Supply interruption before
de-energisation 20 ms 20 ms 20 ms
Simultaneity, channel 1
and 2 max. ∞ ∞ ∞
Environmental data 774060 774061 774062
Climatic suitability EN 60068-2-78 EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -10 - 55 °C -10 - 55 °C -10 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C -40 - 85 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during op-
eration Not permitted Not permitted Not permitted
EMC EN 60947-5-1, EN
61000-6-2, EN 61326-3-1
EN 60947-5-1, EN
61000-6-2, EN 61326-3-1
EN 60947-5-1, EN
61000-6-2, EN 61326-3-1
Vibration
In accordance with the
standard EN 60068-2-6 EN 60068-2-6 EN 60068-2-6
Frequency 10 - 55 Hz 10 - 55 Hz 10 - 55 Hz
Amplitude 0,35 mm 0,35 mm 0,35 mm
Airgap creepage
In accordance with the
standard EN 60947-1 EN 60947-1 EN 60947-1
Overvoltage category III / II III / II III / II
Pollution degree 2 2 2
Rated insulation voltage 250 V 250 V 250 V
