PNOZ e1vp
Operating Manual PNOZ e1vp
21236-EN-06
33
Semiconductor outputs 774132 784132
Switching capability, 1 safety out-
put under load
Current at UB ≤ 26.5 V 2,7 A 2,7 A
Current at UB > 26,5 V 2,2 A 2,2 A
Power at UB ≤ 26.5 V 70 W 70 W
Power at UB > 26,5 V 65 W 65 W
Max. line capacitance at the out-
puts without load 2 nF 2 nF
Voltage auxiliary and test pulse
outputs 24 V 24 V
Current auxiliary and test pulse
outputs 0,5 A 0,5 A
Times 774132 784132
Switch-on delay
After power on 3 s 3 s
With automatic start typ. 100 ms 100 ms
With automatic start max. 180 ms 180 ms
With monitored start typ. 180 ms 180 ms
With monitored start max. 260 ms 260 ms
Logic inputs typ. 120 ms 120 ms
Logic inputs max. 200 ms 200 ms
Response time tr semiconductor
outputs
typ. 40 ms 40 ms
max. 43 ms 43 ms
Maximum time of feedback loop
monitoring 150 ms 150 ms
Delay time tv 0,00 s, 15 s, 25 s, 50 s, 100 s, 150
s, 200 s, 250 s, 300 s
0,00 s, 15 s, 25 s, 50 s, 100 s, 150
s, 200 s, 250 s, 300 s
Time accuracy +/-10 % + 40 ms +/-10 % + 40 ms
Repetition accuracy 5 % 5 %
Supply interruption before de-ener-
gisation 20 ms 20 ms
Simultaneity, channel 1 and 2 max. ∞ ∞
Environmental data 774132 784132
Climatic suitability EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -10 - 55 °C -10 - 55 °C
Storage temperature
Temperature range -25 - 70 °C -25 - 70 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during operation Not permitted Not permitted
EMC EN 60947-5-1, EN 61000-6-2, EN
61000-6-4, EN 61326-3-1
EN 60947-5-1, EN 61000-6-2, EN
61000-6-4, EN 61326-3-1
