Pilz PNOZ m ES Profinet User Manual

Overview
OperatingManualPNOZmESProfinet
1003386EN02
7
2 Overview
2.1 Scopeofsupply
2.2 Unitfeatures
UsingtheproductPNOZmESProfinet:
Expansionmoduleforconnectiontoabaseunitfromtheconfigurablecontrolsystem
PNOZmulti2.
Theproducthasthefollowingfeatures:
} CanbeconfiguredinthePNOZmultiConfigurator
} ConnectionsforPROFINET
} status,diagnosticanderrordisplaysforcommunicationwithPROFINET
} 128virtualinputsandoutputsonthecontrolsystemPNOZmulti2canbedefinedinthe
PNOZmultiConfiguratorforcommunicationwiththefieldbusPROFINET.
} Transmissionrate100MBit/s(100BaseTX),fullandhalfduplex
} Max.1PNOZmESProfinetcanbeconnectedtothebaseunit
} TwoRJ45ports
} ProfinetIOdevice(V2.2)functionsinaccordancewithConformanceClassC
} Supportedfunctions:
– RT
– IRT
– MRP
– LLDP
– I&M04
} Pluginconnectionterminals:
eitherspringloadedterminalorscrewterminalavailableasanaccessory(seeorder
reference)
} Pleaserefertothedocument"PNOZmultiSystemExpansion"fordetailsofthebase
unitsPNOZmulti2thatcanbeconnected.

Pilz PNOZ m ES Profinet Specifications

General

Brand	Pilz
Model	PNOZ m ES Profinet
Category	Control Systems
Language	English
