Pilz PNOZ mm0.1p User Manual

Installation
Operating Manual PNOZ mm0.1p
1002101-EN-04
17
} Fit the appropriate terminator to the unconnected interfaces on the base unit and ex-
pansion module.
– Left-hand side on the base unit and expansion modules to the left of the base unit:
Black/yellow terminator
– Right-hand side on the base unit and expansion modules to the right of the base
unit: Yellow terminator
Left terminator Right terminator
Jumper
CAUTION!
Only connect the base unit and expansion modules when the supply voltage
is switched off.
