Technical details
Operating Manual PNOZ mm0.1p
1002101-EN-04
30
8 Technical details
General
Approvals
BG, CCC, CE, EAC (Eurasian), KCC, TÜV, cULus
Listed
Electrical data
Supply voltage
for Supply to the system
Voltage 24,0 V
Kind DC
Voltage tolerance -15 %/+20 %
Output of external power supply (DC) 35,0 W
Output of external power supply (DC) at no load 8,0 W
Residual ripple DC 5 %
Supply voltage
for Supply to the SC outputs
Voltage 24 V
Kind DC
Voltage tolerance -15 %/+20 %
Output of external power supply (DC) 192,0 W
Status indicator Display, LED
Configurable inputs/outputs (inputs or auxiliary
outputs)
Number 8
Galvanic isolation No
Configurable inputs
Input voltage in accordance with EN 61131-2 Type
1 24,0 V
Input current at rated voltage 5 mA
Min. pulse duration 16 ms
Pulse suppression 0,6 ms
Signal level at "1" 15 ... 30 V DC
Signal level at "0" -3 ... +5 V DC
Maximum input delay 4,0 ms
Configurable auxiliary outputs
Voltage 24,0 V
Output current 75 mA
Power 1,8 W
Short circuit-proof yes
Residual current at "0" 0,5 mA
Voltage at "1" UB - 2 V at 0.1 A
Inputs
Number 12
Signal level at "0" -3 - +5 V DC
Signal level at "1" 15 - 30 V DC
