Technical details
Operating Manual PNOZ mm0.1p
1002101-EN-04
33
Mechanical data
Spring-loaded terminals: Terminal points per connec-
tion
2
Stripping length with spring-loaded terminals 9 mm
Dimensions
Height 100,0 mm
Width 45,0 mm
Depth 120,0 mm
Weight 231 g
Where standards are undated, the 2010-08 latest editions shall apply.
8.1 Safety characteristic data
NOTICE
You must comply with the safety-related characteristic data in order to
achieve the required safety level for your plant/machine.
Unit Operating
mode
EN ISO
13849-1: 2015
PL
EN ISO
13849-1: 2015
Category
EN 62061
SIL CL
EN 62061
PFH
D
[1/h]
EN ISO
13849-1: 2015
T
M
[year]
Logic
CPU 2-channel PL e Cat. 4 SIL CL 3 1,54E-09 20
Expansion
right
– PL e Cat. 4 SIL CL 3 2,13E-10 20
Expansion left – PL e Cat. 4 SIL CL 3 2,38E-10 20
Input
SC inputs 1-channel PL d Cat. 2 SIL CL 2 3,95E-09 20
SC inputs 2-channel PL e Cat. 4 SIL CL 3 4,61E-10 20
SC inputs Short circuit-
forming
safety mats
PL d Cat. 3 SIL CL 2 1,86E-09 20
SC inputs 1-ch., pulsed
light barrier
PL e Cat. 4 SIL CL 3 3,95E-10 20
Output
SC outputs 1-channel
with ad-
vanced fault
detection
PL e Cat. 4 SIL CL 3 7,65E-10 20
SC outputs 1-channel PL d Cat. 2 SIL CL 2 8,90E-10 20
SC outputs 2-channel PL e Cat. 4 SIL CL 3 7,86E-10 20
All the units used within a safety function must be considered when calculating the safety
characteristic data.
