Technical details
Operating Manual PNOZ mm0.1p
1002101-EN-04
32
Environmental data
Vibration
In accordance with the standard EN 60068-2-6
Frequency 10,0 - 150,0 Hz
Acceleration 1g
Shock stress
In accordance with the standard EN 60068-2-27
Acceleration 15g
Duration 11 ms
Max. operating height above sea level 2000 m
Airgap creepage
In accordance with the standard EN 61131-2
Overvoltage category II
Pollution degree 2
Rated insulation voltage 30 V
Rated impulse withstand voltage 2,50 kV
Protection type
In accordance with the standard EN 60529
Mounting area (e.g. control cabinet) IP54
Housing IP20
Terminals IP20
Potential isolation
Potential isolation between SC output and system voltage
Type of potential isolation Basic insulation
Rated surge voltage 2500 V
Mechanical data
Mounting position Horizontal on top hat rail
DIN rail
Top hat rail 35 x 7,5 EN 50022
Recess width 27 mm
Max. cable length
Max. cable length per input 1,0 km
Sum of individual cable lengths at the test pulse
output 2 km
Material
Bottom PC
Front PC
Top PC
Connection type Spring-loaded terminal, screw terminal
Conductor cross section with screw terminals
1 core flexible 0,25 - 2,50 mm², 24 - 12 AWG
2 core with the same cross section, flexible without
crimp connectors or with TWIN crimp connectors 0,20 - 1,50 mm², 24 - 16 AWG
Torque setting with screw terminals 0,50 Nm
Conductor cross section with spring-loaded terminals:
Flexible with/without crimp connector 0,20 - 2,50 mm², 24 - 12 AWG
